6 Conductors PUR Jacket Coiled Spiral Cable

Ask Lasest Price
Brand Name :	Spiral Cable
Model Number :	spiral-cable-021
Certification :	UL, CUL, CSA, AWM, CE
Price :	USD0.12~0.50 per piece
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	800,000pcs per month
Delivery Time :	10 days for ready goods

Add to Cart

Product Details
Company Profile

6 Conductors PUR Jacket Coiled Spiral Cable

6 Conductors PUR Jacket Coiled Spiral Cable

Rated Temperature: 105°C;

Rated Voltage: 300V.

Jacket material: Quality Polyurethane PUR;

Colour: White. Other colours are also available;

Feature: High flex and long flex life;

100% Rohs compliant.

Spiral Cable	Conductor Structure	Insulation Thickness	Nominal Diameter	Screened Coverage	Sheath Thickness	Overall Diameter	Conductor Resistance
Spiral Cable	AWG	mm	mm	%	mm	mm	Ω/KM(20℃)
2C	30	0.23	0.80	≥65	0.89	3.80	381.00
2C	28	0.23	0.90	≥65	0.89	4.10	239.00
2C	26	0.23	1.00	≥65	0.89	4.30	150.00
2C	24	0.23	1.10	≥65	0.89	4.40	94.20
2C	22	0.23	1.30	≥65	0.89	4.80	59.40
2C	20	0.23	1.50	≥65	0.89	5.20	36.70
2C	18	0.23	1.80	≥65	0.89	5.80	23.20
2C	16	0.23	2.00	≥65	0.89	8.00	14.60
3C	30	0.23	0.80	≥65	0.89	5.70	381.00
3C	28	0.23	0.90	≥65	0.89	5.90	239.00
3C	26	0.23	1.00	≥65	0.89	6.10	150.00
3C	24	0.23	1.10	≥65	0.89	6.30	94.20
3C	22	0.23	1.30	≥65	0.89	6.70	59.40
3C	20	0.23	1.50	≥65	0.89	7.20	36.70
3C	18	0.23	1.80	≥65	0.89	7.80	23.20
4C	30	0.23	0.80	≥65	0.89	5.90	381.00
4C	28	0.23	0.90	≥65	0.89	6.10	239.00
4C	26	0.23	1.00	≥65	0.89	6.40	150.00
4C	24	0.23	1.10	≥65	0.89	6.70	94.20
4C	22	0.23	1.30	≥65	0.89	7.10	59.40
4C	20	0.23	1.50	≥65	0.89	7.60	36.70
5C	30	0.23	0.80	≥65	0.89	6.20	381.00
5C	28	0.23	0.90	≥65	0.89	6.50	239.00
5C	26	0.23	1.00	≥65	0.89	6.60	150.00
5C	24	0.23	1.10	≥65	0.89	7.00	94.20
5C	22	0.23	1.30	≥65	0.89	7.60	59.40
6C	30	0.23	0.80	≥65	0.89	6.60	381.00
6C	28	0.23	0.90	≥65	0.89	6.90	239.00
6C	26	0.23	1.00	≥65	0.89	7.20	150.00
6C	24	0.23	1.10	≥65	0.89	7.50	94.20

6 Conductors PUR Jacket Coiled Spiral Cable

Contact:

Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the different requirement.

Tag: coiled cable, spiral cable
