Equipment Spiral Curly Cable

Ask Lasest Price
Brand Name :	Spiral Cable
Model Number :	TH-812475
Certification :	UL, CUL, CSA, AWM, CE
Price :	USD0.14~0.58 per piece
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	800,000pcs per month
Delivery Time :	10 days for ready goods

Add to Cart

Product Details
Company Profile

Equipment Spiral Curly Cable

Equipment Spiral Curly Cable

Pure copper wire conductors.

Pair twisted conductor wires.

Tinned copper braiding shield.

100% RoHS compliant.

Spiral Cable	Conductor Structure	Insulation Thickness	Nominal Diameter	Screened Coverage	Sheath Thickness	Overall Diameter	Conductor Resistance
Spiral Cable	AWG	mm	mm	%	mm	mm	Ω/KM(20℃)
2C	30	0.76	1.90	≥65	0.38	5.80	381.00
2C	28	0.76	2.00	≥65	0.38	6.10	239.00
2C	26	0.76	2.10	≥65	0.38	6.20	150.00
2C	24	0.76	2.20	≥65	0.38	6.40	94.20
2C	22	0.76	2.40	≥65	0.38	6.80	59.40
2C	20	0.76	2.50	≥65	0.38	7.20	36.70
2C	18	0.76	2.80	≥65	0.38	7.80	23.20
2C	16	0.76	3.10	≥65	0.38	10.00	14.60
3C	30	0.76	1.90	≥65	0.38	7.70	381.00
3C	28	0.76	2.00	≥65	0.38	7.90	239.00
3C	26	0.76	2.10	≥65	0.38	8.10	150.00
3C	24	0.76	2.20	≥65	0.38	8.30	94.20
3C	22	0.76	2.40	≥65	0.38	8.70	59.40
3C	20	0.76	2.50	≥65	0.38	9.20	36.70
3C	18	0.76	2.80	≥65	0.38	9.80	23.20
4C	30	0.76	1.90	≥65	0.38	7.90	381.00
4C	28	0.76	2.00	≥65	0.38	8.10	239.00
4C	26	0.76	2.10	≥65	0.38	8.40	150.00
4C	24	0.76	2.20	≥65	0.38	8.70	94.20
4C	22	0.76	2.40	≥65	0.38	9.10	59.40
4C	20	0.76	2.50	≥65	0.38	9.70	36.70
5C	30	0.76	1.90	≥65	0.38	8.20	381.00
5C	28	0.76	2.00	≥65	0.38	8.50	239.00
5C	26	0.76	2.10	≥65	0.38	8.60	150.00
5C	24	0.76	2.20	≥65	0.38	9.00	94.20
5C	22	0.76	2.40	≥65	0.38	9.60	59.40
6C	30	0.76	1.90	≥65	0.38	8.60	381.00
6C	28	0.76	2.00	≥65	0.38	8.90	239.00
6C	26	0.76	2.10	≥65	0.38	9.20	150.00
6C	24	0.76	2.20	≥65	0.38	9.50	94.20

Contact:

Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the different requirement.
