Brand Name : | Spiral Cable |
Model Number : | spiral-cable-009 |
Certification : | UL, CUL, CSA, AWM, CE |
Price : | USD0.25~0.55 per piece |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | 800,000pcs per month |
Delivery Time : | 10 days for ready goods |
Long Flex Performance Anti Flex Fatigue Coil Spiral Cable
Spiral cable provides great solution for application under narrow space condition. Tongheng company staff works hard to catch up with the most advanced technology and creates the best quality spiral cable.
Here below is the product properties:
Manufactured by: China cable factory
Conductor quantity: 2C to 50C
Conductor: oxygen free copper wires
100% RoHS compliant
Product parameters:
Spiral Cable | Conductor Structure | Insulation Thickness | Nominal Diameter | Screened Coverage | Sheath Thickness | Overall Diameter | Conductor Resistance |
No/mm | mm | mm | % | mm | mm | Ω/KM(20℃) | |
2C | 7/0.100 | 0.23 | 0.80 | ≥65 | 0.76 | 3.80 | 381.00 |
2C | 7/0.127 | 0.23 | 0.90 | ≥65 | 0.76 | 4.00 | 239.00 |
2C | 7/0.16 | 0.23 | 1.00 | ≥65 | 0.76 | 4.10 | 150.00 |
2C | 11/0.16 | 0.23 | 1.10 | ≥65 | 0.76 | 4.20 | 94.20 |
2C | 17/0.16 | 0.23 | 1.30 | ≥65 | 0.76 | 4.60 | 59.40 |
2C | 21/0.178 | 0.23 | 1.50 | ≥65 | 0.76 | 5.00 | 36.70 |
2C | 34/0.178 | 0.23 | 1.80 | ≥65 | 0.76 | 5.60 | 23.20 |
2C | 26/0.25 | 0.23 | 2.00 | ≥65 | 0.76 | 7.80 | 14.60 |
3C | 7/0.100 | 0.23 | 0.80 | ≥65 | 0.76 | 4.00 | 381.00 |
3C | 7/0.127 | 0.23 | 0.90 | ≥65 | 0.76 | 4.20 | 239.00 |
3C | 7/0.16 | 0.23 | 1.00 | ≥65 | 0.76 | 4.40 | 150.00 |
3C | 11/0.16 | 0.23 | 1.10 | ≥65 | 0.76 | 4.60 | 94.20 |
3C | 17/0.16 | 0.23 | 1.30 | ≥65 | 0.76 | 5.20 | 59.40 |
3C | 21/0.178 | 0.23 | 1.50 | ≥65 | 0.76 | 5.50 | 36.70 |
3C | 34/0.178 | 0.23 | 1.80 | ≥65 | 0.76 | 6.10 | 23.20 |
4C | 7/0.100 | 0.23 | 0.80 | ≥65 | 0.76 | 4.20 | 381.00 |
4C | 7/0.127 | 0.23 | 0.90 | ≥65 | 0.76 | 4.40 | 239.00 |
4C | 7/0.16 | 0.23 | 1.00 | ≥65 | 0.76 | 4.70 | 150.00 |
4C | 11/0.16 | 0.23 | 1.10 | ≥65 | 0.76 | 5.10 | 94.20 |
4C | 17/0.16 | 0.23 | 1.30 | ≥65 | 0.76 | 5.40 | 59.40 |
4C | 21/0.178 | 0.23 | 1.50 | ≥65 | 0.76 | 5.90 | 36.70 |
5C | 7/0.100 | 0.23 | 0.80 | ≥65 | 0.76 | 4.40 | 381.00 |
5C | 7/0.127 | 0.23 | 0.90 | ≥65 | 0.76 | 4.60 | 239.00 |
5C | 7/0.16 | 0.23 | 1.00 | ≥65 | 0.76 | 4.70 | 150.00 |
5C | 11/0.16 | 0.23 | 1.10 | ≥65 | 0.76 | 5.10 | 94.20 |
5C | 17/0.16 | 0.23 | 1.30 | ≥65 | 0.76 | 5.70 | 59.40 |
6C | 7/0.100 | 0.23 | 0.80 | ≥65 | 0.76 | 4.60 | 381.00 |
6C | 7/0.127 | 0.23 | 0.90 | ≥65 | 0.76 | 5.00 | 239.00 |
6C | 7/0.16 | 0.23 | 1.00 | ≥65 | 0.76 | 5.40 | 150.00 |
6C | 11/0.16 | 0.23 | 1.10 | ≥65 | 0.76 | 5.70 | 94.20 |
Tag: spiral cable, coiled cable
![]() |
