UK Customer Preferred Factory Supplied Coil Spiral Cable

Dongguan Tongheng Electronics Co., Ltd.
Contact Now
    Buy cheap UK Customer Preferred Factory Supplied Coil Spiral Cable from wholesalers

    Buy cheap UK Customer Preferred Factory Supplied Coil Spiral Cable from wholesalers
    • Buy cheap UK Customer Preferred Factory Supplied Coil Spiral Cable from wholesalers

    UK Customer Preferred Factory Supplied Coil Spiral Cable

    Ask Lasest Price
    Brand Name : Spiral Cable
    Model Number : spiral-cable-002
    Certification : UL, CUL, CSA, AWM, CE
    Price : USD0.25~0.56 per piece
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 800,000pcs per month
    Delivery Time : 10 days for ready goods
    • Product Details
    • Company Profile

    UK Customer Preferred Factory Supplied Coil Spiral Cable

    UK Customer Preferred Factory Supplied Coil Spiral Cable


    We manufacture good quality spiral cable. Some are so popular among the UK markets. With the excellent quality performance, we earn the trust from the UK, and other markets around the world.


    Here below is the product properties:


    Conductors quantity: 2 to 50C

    High temperature rated: 105C degrees

    Rated Voltage: 300V

    Insulation material: Thermoplastic polypropylene PP

    Sheath material: polyurethane PUR.


    Product parameters:


    Spiral CableConductor StructureInsulation ThicknessNominal DiameterScreened CoverageSheath ThicknessOverall DiameterConductor Resistance
    No/mmmmmm%mmmmΩ/KM(20℃)
    2C7/0.1000.761.90≥650.766.00381.00
    2C7/0.1270.762.00≥650.766.30239.00
    2C7/0.160.762.10≥650.766.40150.00
    2C11/0.160.762.20≥650.766.6094.20
    2C17/0.160.762.40≥650.767.0059.40
    2C21/0.1780.762.50≥650.767.4036.70
    2C34/0.1780.762.80≥650.768.0023.20
    2C26/0.250.763.10≥650.7610.2014.60
    3C7/0.1000.761.90≥650.767.90381.00
    3C7/0.1270.762.00≥650.768.10239.00
    3C7/0.160.762.10≥650.768.30150.00
    3C11/0.160.762.20≥650.768.5094.20
    3C17/0.160.762.40≥650.768.9059.40
    3C21/0.1780.762.50≥650.769.4036.70
    3C34/0.1780.762.80≥650.7610.0023.20
    4C7/0.1000.761.90≥650.768.10381.00
    4C7/0.1270.762.00≥650.768.30239.00
    4C7/0.160.762.10≥650.768.60150.00
    4C11/0.160.762.20≥650.768.9094.20
    4C17/0.160.762.40≥650.769.3059.40
    4C21/0.1780.762.50≥650.769.8036.70
    5C7/0.1000.761.90≥650.768.40381.00
    5C7/0.1270.762.00≥650.768.70239.00
    5C7/0.160.762.10≥650.768.80150.00
    5C11/0.160.762.20≥650.769.2094.20
    5C17/0.160.762.40≥650.769.8059.40
    6C7/0.1000.761.90≥650.768.80381.00
    6C7/0.1270.762.00≥650.769.10239.00
    6C7/0.160.762.10≥650.769.40150.00
    6C11/0.160.762.20≥650.769.7094.20
