Brand Name : | Fire Retardant Cable |
Model Number : | TH-830137 |
Certification : | UL, CSA, AWM |
Price : | USD0.18~0.45 per meter |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | 10,000,000 meters monthly |
Delivery Time : | 5~10 working days |
Tinned Copper Spiral Shield Screended Fire Resistant FT1 Grade Customized Electrical Cable
Customized Cable is the most featured products of Tongheng business. Tinned Copper Spiral Shield Screended Fire Resistant FT1 Grade Customized Electrical Cable is created strictly following customers requirement. As the professional manufacturer, Tongheng staff engage to create customer the best quality cable. Tinned Copper Spiral Shield Screended Fire Resistant FT1 Grade Customized Electrical Cable is one of the excellent example. Its remarkable advantage is fire resistant FT1 grade.
Here below is the product properties:
Conductors: high purity copper wires
Fire resistant grade: FT1
Shield type: tinned copper spiral shield screened
Spec to be customized per customers requirement.
Product parameters:
Fire Cable | Conductor Structure | Insulation Thickness | Nominal Diameter | Screened Coverage | Sheath Thickness | Overall Diameter | Conductor Resistance |
AWG | mm | mm | % | mm | mm | Ω/KM(20℃) | |
2C | 30 | 0.76 | 1.90 | ≥65 | 0.38 | 5.80 | 381.00 |
2C | 28 | 0.76 | 2.00 | ≥65 | 0.38 | 6.10 | 239.00 |
2C | 26 | 0.76 | 2.10 | ≥65 | 0.38 | 6.20 | 150.00 |
2C | 24 | 0.76 | 2.20 | ≥65 | 0.38 | 6.40 | 94.20 |
2C | 22 | 0.76 | 2.40 | ≥65 | 0.38 | 6.80 | 59.40 |
2C | 20 | 0.76 | 2.50 | ≥65 | 0.38 | 7.20 | 36.70 |
2C | 18 | 0.76 | 2.80 | ≥65 | 0.38 | 7.80 | 23.20 |
2C | 16 | 0.76 | 3.10 | ≥65 | 0.38 | 10.00 | 14.60 |
3C | 30 | 0.76 | 1.90 | ≥65 | 0.38 | 7.70 | 381.00 |
3C | 28 | 0.76 | 2.00 | ≥65 | 0.38 | 7.90 | 239.00 |
3C | 26 | 0.76 | 2.10 | ≥65 | 0.38 | 8.10 | 150.00 |
3C | 24 | 0.76 | 2.20 | ≥65 | 0.38 | 8.30 | 94.20 |
3C | 22 | 0.76 | 2.40 | ≥65 | 0.38 | 8.70 | 59.40 |
3C | 20 | 0.76 | 2.50 | ≥65 | 0.38 | 9.20 | 36.70 |
3C | 18 | 0.76 | 2.80 | ≥65 | 0.38 | 9.80 | 23.20 |
4C | 30 | 0.76 | 1.90 | ≥65 | 0.38 | 7.90 | 381.00 |
4C | 28 | 0.76 | 2.00 | ≥65 | 0.38 | 8.10 | 239.00 |
4C | 26 | 0.76 | 2.10 | ≥65 | 0.38 | 8.40 | 150.00 |
4C | 24 | 0.76 | 2.20 | ≥65 | 0.38 | 8.70 | 94.20 |
4C | 22 | 0.76 | 2.40 | ≥65 | 0.38 | 9.10 | 59.40 |
4C | 20 | 0.76 | 2.50 | ≥65 | 0.38 | 9.70 | 36.70 |
5C | 30 | 0.76 | 1.90 | ≥65 | 0.38 | 8.20 | 381.00 |
5C | 28 | 0.76 | 2.00 | ≥65 | 0.38 | 8.50 | 239.00 |
5C | 26 | 0.76 | 2.10 | ≥65 | 0.38 | 8.60 | 150.00 |
5C | 24 | 0.76 | 2.20 | ≥65 | 0.38 | 9.00 | 94.20 |
5C | 22 | 0.76 | 2.40 | ≥65 | 0.38 | 9.60 | 59.40 |
6C | 30 | 0.76 | 1.90 | ≥65 | 0.38 | 8.60 | 381.00 |
6C | 28 | 0.76 | 2.00 | ≥65 | 0.38 | 8.90 | 239.00 |
6C | 26 | 0.76 | 2.10 | ≥65 | 0.38 | 9.20 | 150.00 |
6C | 24 | 0.76 | 2.20 | ≥65 | 0.38 | 9.50 | 94.20 |
Tinned Copper Spiral Shield Screended Fire Resistant FT1 Grade Customized Electrical Cable
Contact:
Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the different requirement.
Tag: spiral cable, ft1 spiral cable, ul20084
![]() |
